SpeTool 5PCS 2 Flute 1/4 SHK Ball Nose End Mill Cutter CNC Router Bits
SpeTool 5PCS 2 Flute 1/4 SHK Ball Nose End Mill Cutter CNC Router Bits
SpeTool 5PCS 2 Flute 1/4 SHK Ball Nose End Mill Cutter CNC Router Bits
SpeTool 5PCS 2 Flute 1/4 SHK Ball Nose End Mill Cutter CNC Router Bits
SpeTool 5PCS 2 Flute 1/4 SHK Ball Nose End Mill Cutter CNC Router Bits
SpeTool 5PCS 2 Flute 1/4 SHK Ball Nose End Mill Cutter CNC Router Bits

SpeTool M02002 - Espiral CNC SC para acero, metal de acero inoxidable con revestimiento TiAlN, 2 flautas, 1/4" de diámetro x 1/4" de vástago x 3/4" de longitud de corte x 2-1/2" de largo, punta de bola hacia arriba, fresas de extremo cortadas

SKU: P2B-R1/8-FBA-5PCS
$45.99 USD

Envío calculado en la compra

Ball Nose Router Bits feature a rounded tip for smooth contouring and precise cutting. Built for durability, they handle wood, carbon steel, mould steel, Inconel, stainless steel, and titanium alloy with clean, consistent results

Excellent For Cutting:

  • Wood
  • Carbon steel
  • Mould steel
  • Inconel
  • Stainless steel
  • Titanium alloy

Especificación:

numero de flauta

2

Tipo de corte final

Nariz de bola

Diámetro del vástago (SD)

1/4"

Diámetro de corte (CD)

1/4"

Longitud de corte (CL)

3/4"

Longitud total (OVL)

2-1/2"

Revestimiento

TiAlN

Material Carburo



Descripción general:

Para una vida útil más larga de la herramienta y un mejor acabado en aplicaciones de fresado de uso general, estas fresas de mango de carburo sólido son más duras, más fuertes y más resistentes al desgaste que las fresas de acero de alta velocidad y de acero de cobalto. Su extrema dureza significa que son frágiles, por lo que es necesaria una configuración muy rígida, como una máquina CNC, para evitar que la fresa se rompa.

Las fresas con revestimiento de TiAlN disipan el calor mejor que otras fresas, especialmente a altas velocidades. A altas temperaturas, el recubrimiento crea una capa de óxido de aluminio que transfiere calor a las virutas, manteniendo la herramienta fría, incluso cuando se usa sin lubricación.

Diseñado para cortar los siguientes materiales:

Hierro fundido

Titanio

Acero: 40-50HRC

Acero carbono

Cromo

Acero inoxidable

Soldaduras de acero

Metales ferrosos


28 en existencias
Cantidad:
Payment & Security
American Express Mastercard PayPal Visa Union Pay Apple Pay Google Pay Shop Pay Klarna Afterpay

Your payment details are securely processed. We never store or have access to your credit card information, ensuring complete privacy and safety.

Local delivery
Free shipping
90-day Refund
365-Day Warranty

Similar Size

Part No.

Radius
(R)

Cutting Dia.
(D)

Cutting Height
(B)

Shank Dia.
(d)

Overall Length
(L)

 Flute Coating Rec. RPM
M02001 1/8" 1/4" 1-1/8" 1/4" 3" 2 TiAlN 12,000
*M02001-SPE-X 1/8" 1/4" 1-1/8" 1/4" 3" 2 TAC 12,000
M02002 1/8" 1/4" 3/4" 1/4" 2-1/2" 2 TiAlN 12,000
M03001 1/16" 1/8" 1/2" 1/8" 1-1/2" 2 TiAlN 12,000
M03004 1/32" 1/16" 3/16" 1/8" 1-1/2" 2 TiAlN 12,000
M03005 1/64" 1/32" 5/16" 1/8" 1-1/2" 2 TiAlN 12,000
M04001 3/16" 3/8" 1-1/8" 3/8" 3" 2 TiAlN 12,000
M02005 1/8" 1/4" 1-1/8" 1/4" 3" 4 TiAlN 12,000
M03003 1/16" 1/8" 1/2" 1/8" 1-1/2" 4 TiAlN 18,000

*Customized sizes are acceptable

Frequently Asked Questions

Ball nose bits are ideal for machining soft metals like aluminum and copper, as well as plastics and composites. However, they are generally not suitable for cutting hardened steels or ferrous alloys due to their geometry and the risk of tool wear.

Coatings like TiAlN and TiCN enhance wear resistance and thermal stability. TiAlN is particularly effective for high-heat applications, while TiCN offers better lubrication for softer metals. However, TiAlN-coated tools should be used dry, as coolant can interfere with the formation of the protective aluminum oxide layer.

Coated bits, such as those with TiAlN or TiCN, generally provide better surface finishes and longer tool life compared to uncoated bits. Users have reported that coated bits maintain sharpness and produce cleaner cuts over extended use.

Cutting steel with Ball Nose bits is challenging due to their geometry and the material's hardness. While some hobbyists have attempted it, it's generally not recommended without specialized equipment and tooling.

Customer Reviews

Based on 8 reviews
100%
(8)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
M
Martin Wade

they performed as expected.

D
DOUGLAS S.

I have used other Spetool bits in the past and when I needed a new ball nose bit decided to give them a try. I am satisfied with the quality but they tend to dull a little quicker than the more expensive bits

B
Buddy W.

Worked very good as you can see in the picture only thing I didnt like was real long tool because I have limited z travel on my cnc
